AFL3-W15A-BT 15.6" Fanless Touch Panel PC

  • 15.6" 1366x768 TFT LCD with Resistive Touch Screen
  • Intel® Celeron® J1900 2.0GHz Quad Core Processor
  • 320GB 2.5" 5.4K RPM SATA Hard Drive
  • 2GB DDR3L 1600MHz SO-DIMM Memory
  • Built-in 802.11b/g/n Wireless LAN Module
  • Selectable AT/ATX Power Mode
  • IP64 Compliant Front Bezel
Status: 4 to 8 Weeks Lead-Time
$1,429.00

AFL3-W15A-BT is an ultra slim and power efficient industrial fanless panel PC which supports Intel Celeron J1900 2.0GHz quad core processor, 15.6" 1366x768 LED backlight resistive touch screen, two gigabit Ethernet ports, IEEE802.11b/g/n wireless LAN, two USB3.0 and two COM ports. It also supports Microsoft Windows 7 Embedded and Windows 8 Embedded operating systems. AFL3-W15A-BT is suitable for a wide range of industrial and commercial applications in the market, such as POS, Kiosk, transportation and building automation systems.

AFL3-W15A-BT is an ultra slim and power efficient industrial fanless panel PC which supports Intel Celeron J1900 2.0GHz quad core processor, 15.6" 1366x768 LED backlight resistive touch screen, two gigabit Ethernet ports, IEEE802.11b/g/n wireless LAN, two USB3.0 and two COM ports. It also supports Microsoft Windows 7 Embedded and Windows 8 Embedded operating systems. AFL3-W15A-BT is suitable for a wide range of industrial and commercial applications in the market, such as POS, Kiosk, transportation and building automation systems.

Products Specifications
Attribute nameAttribute value
LCD Size15.6" Wide Screen
Max Resolution1366 x 768
Brightness300nits
Contrast Ratio700:1
LCD Color262K
Pixel Pitch (mm)0.240(H) x 0.240(V)
Viewing Angle (H-V)160°(H) / 160°(V)
Backlight MTBF50000 hrs
Touch Screen5-Wire Resistive Type or Projected Capacitive Type Touch Screen
Touch ControllerPenMount DMC9000 / EETI EXC7200
CPUIntel® Celeron® J1900
MemoryBuilt-in 2GB DDR3L Memory
Max Memory8GB DDR3 SO-DIMM
Ethernet ControllerRealtek RTL8111E PCIe GbE Controller
Audio CodecRealtek ALC892 HD Audio Codec
RS232 COM Port2x RS232 (DB9)
USB 3.0 Port2x USB 3.0
Gigabit LAN Port2x Gigabit LAN Port (RJ-45)
AudioAMP 2W (Internal Speaker)
SSDmSATA
WirelessIEEE802.11 b/g/n Wireless LAN Module (Internal Mini PCIe Interface)
Construction MaterialPC + ABS Plastic Front Frame
MountingPanel, Wall, Stand, Rack and Arm VESA 100mm x 100mm
Front Panel ColorBlack
Operating Temperature-4°F ~ 122°F (-20°C~50°C)
Storage Temperature-4°F ~ 140°F (-20°C~60°C)
Humidity10% to 95% (Non-Condensing)
IP LevelIP64 Compliant Front Panel
Safety & EMCCE/FCC
Power Adapter60W Power Adapter Input: 90VAC~264VAC, 50/60Hz
Power Requirement12VDC
