WAFER-OT-Z670 3.5" Embedded Board

  • Built-in Intel® Atom™ Z670 1.5GHz Processor
  • Intel® SM35 Chipset
  • On-Board 1GB DDR2 SDRAM
  • 1x 10/100Mbps Ethernet Controller
  • 4x RS-232 Port
  • 1x SD Card Slot
  • One Key Recovery Solution for Backup and Recover
Status: 1 to 2 Weeks Lead-Time
$360.00
Product tags

WAFER-OT-Z670 is a 3.5" embedded board which built-in ultra low power Intel Atom Z670 1.5GHz processor, on-board 1GB 800MHz DDR2 memory, HDMI and LVDS dual display, one SD card slot, seven USB2.0 ports, four COM ports and one SATA 3.0Gbps port. It is ideal for low power consumption and space concernd applications.

Specification

CPU Intel® Atom™ Z670 1.5GHz Processor
System Chipset Intel® SM35
System Memory On-Board 1GB 800MHz DDR2 SDRAM
BIOS AMI BIOS
Ethernet 1x 10/100Mbps LAN Port
I/O Interface

4x RS-232

7x USB2.0

1x SATA3.0Gbps

1x SD Card Slot

Audio Realtek ALC662HD Audio Codec
Display Interface

1x HDMI

1x 18-bit Single Channel LVDS

Power Supply 12V DC (AT/ATX Power Selected by Jumper)
Operating Temperature

14ºF ~ 140ºF (-10ºC ~ 60ºC)

Operating Humidity 5% ~ 95% Relative Humidity, Non-Condensing
Dimension 5.75" x 4.02" (146mm x 102mm)
Net Weight 0.29lbs (0.13kg)
GW Weight 0.99lbs (0.45kg)

Packing List

1x WAFER-OT-Z670 3.5" Embedded Board
1x SATA with Power Cable (P/N: 32801-000201-100-RS)
3x RS-232 Cable (P/N: 32205-002700-100-RS)
1x Audio Cable (P/N: 32000-072100-RS)
1x USB Cable (P/N: 32001-002700-200-RS)
1x QIG
1x Mini Jumper Pack
1x Utility CD
1x One Key Recovery CD
