WAFER-CV-N28001 3.5" Embedded Board

  • Built-in Intel® Atom™ N2800 1.86GHz Processor
  • Intel® NM10 Chipset
  • 1x 204-pin DDR3 SDRAM SO-DIMM (Max. 4GB)
  • 2x Gigabit Ethernet Controller
  • 3x RS-232 and 1x RS-422/485 Port
  • 2x PCIe Mini Card
  • One Key Recovery Solution for Backup and Recover
Status: 1 to 2 Weeks Lead-Time
$370.00
Product tags

WAFER-CV-N28001 is a 3.5" embedded board which built-in ultra low power Intel Atom N2800 1.86GHz dual core processor, DDR3 1333/1066MHz memory up to 4GB, one PCIe mini card slot for mSATA SSD storage, six USB2.0 ports, four COM ports and two SATA 3.0Gbps ports. It is ideal for low power consumption and space concernd applications.

Specification

CPU Intel® Atom™ N2800 Dual Core 1.86GHz Processor
System Chipset Intel® NM10
System Memory 1x 204-pin DDR3 1333/1066MHz SO-DIMM (Max. 4GB)
BIOS UEFI BIOS
Ethernet 2x Gigabit Ethernet LAN Port
I/O Interface

3x RS-232

1x RS-422/485

6x USB2.0

2x SATA3.0Gbps

1x 6-pin Wafer for Keyboard and Mouse

Digital I/O 8-bit Digital I/O, 4-bit Input/4-bit Output
Super I/O Fintek F81866
Audio Realtek ALC662HD Audio Codec
Display Interface

1x VGA

1x 18-bit Single Channel LVDS

1x 24-bit Dual Channel LVDS

Expansion

1x Full-Size PCIe Mini Card Slot supporting mSATA SSD Storage

1x Half-Size PCIe Mini Card Slot

Watchdog Timer Software Programmable supports 1~255 sec. System Reset
Power Supply 12V DC (AT/ATX Power Selected by Jumper)
Operating Temperature

-4ºF ~ 158ºF (-20ºC ~ 70ºC) with Free Air

-4ºF ~ 167ºF (-20ºC ~ 75ºC) with Force Air

Operating Humidity 5% ~ 95% Relative Humidity, Non-Condensing
Dimension 5.75" x 4.02" (146mm x 102mm)
Net Weight 0.55lbs (0.25kg)
GW Weight 1.32lbs (0.60kg)

Packing List

1x WAFER-CV-N28001 3.5" Embedded Board
2x SATA with Power Cable (P/N: 32801-000201-100-RS)
1x RS-232 Cable (P/N: 32205-002700-100-RS)
1x KB/MS Cable (P/N: 32000-023800-RS)
1x Power Cable (P/N: 32100-087100-RS)
1x Screw Set for PCIe Mini Card
1x Enclosure Heatsink
1x QIG
1x Mini Jumper Pack
1x Utility CD
1x One Key Recovery CD
